BAR CUTTING MACHINE

Description

A BAR CUTTING MACHINE also known as a rebar cutter, is an essential tool in construction and fabrication industries where steel reinforcement bars (rebars) need to be cut to specific lengths.

Purpose:

• Cutting Reinforcement Bars: The primary function of a bar cutting machine is to cut steel reinforcement bars (rebars) to the desired length accurately and efficiently.

Components:

• Cutting Blades: High-strength blades designed to cut through steel bars of various diameters.
• Feeding Mechanism: Allows operators to feed the steel bars into the machine for cutting.
• Control Panel: Where operators can input cutting lengths and operate the machine.
• Safety Features: Guards and sensors to ensure safe operation.

• Advantages:

  • Precision: Ensures precise cutting lengths consistently.
  • Efficiency: Speeds up the cutting process compared to manual methods.
  • Reduced Labor: Minimizes the need for manual labor in cutting reinforcement bars.

Technical Details for Bar Cutting Machine

1. Model: GQ 40, GQ 50

2. Cutting Capacity:

   • Diameter of Bar: (e.g., 6mm to 40mm)

   • Maximum Cutting Length: (e.g., Up to 6 meters or custom lengths)

3. Cutting Blade Type:

   • (e.g., High-speed steel blade, Tungsten carbide blade)

4. Motor Power:

   • (e.g., 3 HP, 5 HP, 7.5 HP, depending on the machine model)

5. Voltage:

   • (e.g., 415V, 50Hz, 3-phase)

6. Cutting Speed:

   • (e.g., 30–40 cuts per minute depending on bar diameter and material)

7. Cutting Accuracy:

   • (e.g., ±1mm)

8. Dimensions (L x W x H):

   • (e.g., 1300 mm x 700 mm x 1100 mm)

9. Weight:

   • (e.g., 400 kg)

10. Control System:

    • (e.g., PLC, manual switch, or digital control panel)

11. Hydraulic System:

    • (e.g., Hydraulic-powered cutting mechanism for ease and force)

12. Cutting Pressure:

    • (e.g., 120 bar for hydraulic cutting)

13. Safety Features:

    • Emergency stop button, overload protection, safety guard rails, and protective covers.

14. Feeding Mechanism:

    • (e.g., Manual or Automatic feeding of bars into the cutting zone)

15. Cutting Angle:

    • (e.g., Straight cutting, or angular cutting options)

16. Lubrication System:

    • (e.g., Automatic lubrication system to keep components running smoothly)

17. Bar Length Adjustment:

    • (e.g., Adjustable length stops or digital settings for precise cutting)

18. Max Cutting Force:

    • (e.g., 25 tons of force)

19. Cooling System:

    • (e.g., Air or oil cooling system for blades to prevent overheating)

20. Noise Level:

    • (e.g., 75-80 dB during operation)
